Samsung Patents a Switchable Satellite Antenna Built Into a Phone's Metal Frame

By Patentlyze Team · Updated Jul 10, 2026

Samsung is figuring out how to hide a satellite antenna inside the metal rim of a phone, using a small switch to flip between two antenna setups depending on what the signal needs.

What Samsung's metal-frame satellite antenna actually does

Imagine your phone's metal edges doing double duty: not just framing the glass, but also pulling in satellite signals from space. That's the core idea in this Samsung patent.

Inside a typical phone, the metal frame around the screen already acts as a Wi-Fi or cellular antenna. Samsung's patent extends that idea to satellite communication, carving out a section of the metal housing to specifically handle satellite frequency bands. A second, separate antenna sits inside the phone body and can team up with the first one when needed.

A tiny electronic switch on the phone's circuit board is the key piece. It decides whether that inner antenna connects to the outer frame antenna, or gets linked to ground (essentially switched off or neutralized). That gives the phone two different antenna configurations to work with, which helps it catch weaker signals from satellites orbiting far overhead.

How the switch connects the two antenna structures

The patent describes a dual-antenna architecture for satellite communication inside a smartphone. The two antenna structures work together, controlled by a single switch on the printed circuit board.

• First antenna structure: formed directly from a portion of the phone's conductive housing (the metal frame). It is tuned to support satellite communication frequency bands.
• Second antenna structure: a separate antenna placed inside the housing that can be electrically connected to the first antenna structure.
• Switch: one end connects to the second antenna; the other end connects to ground. By toggling the switch, the device either links the two antennas together or shunts the second antenna to ground, changing the overall antenna's shape and electrical behavior.

Connecting or disconnecting the second antenna effectively changes the resonant length of the combined antenna system (resonant length meaning the physical size that determines which radio frequencies it captures best). Satellite signals operate at specific frequency bands that differ from standard cellular, so this adjustability helps the phone tune itself for those weaker, longer-distance signals without requiring a large external antenna component.

What this means for satellite connectivity in Galaxy phones

Satellite messaging is moving from a niche emergency feature to a mainstream expectation. Apple added it to the iPhone 14, and carriers are racing to offer direct-to-satellite texting. Samsung filing a patent around integrating satellite antenna hardware into the metal housing suggests the company is working on its own approach, one that avoids bolting on extra antenna hardware by repurposing the frame that's already there.

For you as a user, the practical upside is a phone that can reach a satellite when you're off the grid, without the device getting thicker or heavier. The switch-based design also hints at the phone being able to adapt its antenna for different modes, regular cellular when you're in a city, satellite-optimized when you're not, without you doing anything at all.

Editorial commentary on a publicly published patent application. Not legal advice.
